Flash on a slider mould grew from 0.02 mm to 0.15 mm over three weeks, and nobody measured it until parts started catching in the die. The parting line had worn at the core pin area, and clamp tonnage had never been verified.

This intermediate case guide covers flash measurement, parting line wear checks, clamp tonnage and the inspection schedule that catches wear early.

Flash target
Under 0.05 mm parting line
Action threshold
0.10-0.15 mm
Measurement
Weekly feeler gauge
Clamp tonnage
Per die calculation
Spotting
80% ink contact or more
Flash That Grew Over Three Weeks: Parting Line Wear Found Before It Became Expensive
Flash That Grew Over Three Weeks: Parting Line Wear Found Before It Became Expensive
A trio of industrial parts, which appear to be a combination of mechanical and molded components
A trio of industrial parts, which appear to be a combination of mechanical and molded components
Clean assembly line factory floor
Clean assembly line factory floor

Common Mistakes and How to Avoid Them

MistakeWhy It HappensPractical Fix
1. Flash never measuredWear grows unseenFeeler gauge weekly
2. Wear blamed on steel onlyClamp and alignment missedCheck tonnage and die set
3. Tonnage set by habitLow clamp grows flashCalculate per projected area
4. Vents erodedFlash appears at vents firstInspect vent depth 0.05-0.15 mm
5. Spotting skippedPoor contact hides wearSpot after every service
6. Dowels and bushes wornMisalignment opens the lineCheck die set alignment monthly
7. Flash toleratedCatching parts stop the lineAct at 0.10-0.15 mm
8. Service by failureWear becomes damageService by shot count
9. No flash logTrend invisibleLog flash per mould weekly

Best Practices

  • Measure parting line flash weekly with a feeler gauge
  • Verify clamp tonnage against the die calculation
  • Spot the parting surfaces after every service
  • Inspect vent depth and erosion per set-up
  • Check die set alignment monthly
  • Log flash per mould to see the trend

Implementation Roadmap

StepFrequency
Measure flashWeekly per mould
Verify tonnagePer set-up and machine move
Spot parting lineAfter every service
Check alignmentMonthly
Service by shot countPer mould schedule

Flash control flow

  1. Measure - Feeler gauge weekly. (Unmeasured flash grows for weeks.)
  2. Verify - Tonnage and alignment. (Low clamp opens the line.)
  3. Service - Spot and refit by shot count. (Failure-based service damages steel.)
  4. Log - Flash per mould weekly. (No log, no trend, no early catch.)

Flash is a symptom of clearance, tonnage and alignment. | A weekly feeler gauge beats a monthly surprise.

Parting line data

Reference values for mould flash control.

ParameterReferenceWhy It Matters
Parting line targetUnder 0.05 mmNew or refitted moulds hold this
Flash action level0.10-0.15 mmService before parts catch
Clamp tonnageProjected area x 500-700 bar (zinc)Per die, not per habit
Vent depth0.05-0.15 mmEroded vents flash first
Spotting coverage80% ink contact or morePoor contact means wear or misalignment
Alignment checkMonthly, dowel and bushWear opens the parting line
Service triggerPer shot count, e.g. 50k-100kPreventive, not reactive

Flash growth log

WeekFlash mmAction
Week 10.02Monitor
Week 20.06Monitor
Week 30.15Service, check tonnage
After refitUnder 0.05Resume log

Case 1 - flash caught at 0.15 mm before a stoppage

Scenario. Flash on a zinc slider mould grew from 0.02 mm to 0.15 mm over three weeks. Parts began catching in the die and the line stopped twice; the parting line had worn at the core pin area.

Action. Weekly flash measurement with a feeler gauge was started, clamp tonnage was verified against the projected area, the worn area was refitted and spotted to 90 percent ink contact, and the mould joined a shot-count service schedule.

Result. Flash returned below 0.05 mm, catching stopped, and the mould reached its next service without a line stop.

Case 2 - flash appeared after a machine move

Scenario. A bag frame mould produced clean parts for a year, then flashed within days of being moved to a smaller machine with less clamp force.

Action. The move triggered no tonnage check. The clamp force was calculated, the die was returned to a machine at rating, and a machine-move rule was added: verify tonnage before the first shot.

Result. Flash disappeared, and the move rule became part of the set-up sheet.

Frequently Asked Questions

How do I measure flash?

A feeler gauge at the parting line, weekly, at the same points each time.

What flash is acceptable?

Under 0.05 mm on a healthy mould; act at 0.10-0.15 mm before parts catch.

Why did flash grow slowly?

Wear is gradual; without measurement it is invisible until parts catch.

Is flash always wear?

No - low clamp tonnage and die set misalignment open the line too.

How do I check tonnage?

Calculate from projected area and cavity pressure, then verify on the machine display.

What is spotting?

Inking the parting surfaces and closing to check contact; aim for 80 percent or more.

How deep should vents be?

0.05-0.15 mm; deeper vents flash, blocked vents trap gas.

When should I service the mould?

By shot count, about every 50k-100k shots for this part class, not after failure.

Why log flash weekly?

The trend shows wear rate; a jump from 0.06 to 0.15 in one week means tonnage or alignment.

What Would You Like to Solve?

Tell us your flash pattern, machine tonnage and service history, and we can work through the measurement and tonnage checks for your moulds.
