Barrel Loading Reference Card by Part Type: Weights, Volumes and Mix Ratios.
This is a working reference, not theory: every table and checklist here is designed to be printed and used at the line. It complements the failure case studies published in the Technician Hub with the standard documents those cases eventually produced.
Common Mistakes and How to Avoid Them
| Mistake | Why It Happens | Practical Fix |
|---|---|---|
| 1. Loading to full volume | Parts stop tumbling, coverage fails | Hold 35-45% volume; weigh loads |
| 2. Same speed for every part | Heavy parts bruise, light parts carry | Match rotation to part sensitivity |
Best Practices
- Weigh every load; post the chart on the drum
- Five-minute first-load check each shift
- Separate drums for delicate part families
Load and Start Sequence
- Weigh the load - Compare to drum chart (Volume is not weight)
- Set current and ramp - From the loading chart (Do not exceed chart amps)
- 5-minute first-load check - Coverage and contact (Stop and fix before full cycle)
Chart laminated on each drum | Weigh scale calibrated weekly
Barrel Loading and Current Reference
Starting reference for zinc alloy small parts in barrel nickel.
| Parameter | Reference | Why It Matters |
|---|---|---|
| Load fraction | 35-45% drum volume | More stops tumbling; less cuts throughput |
| Current density | 0.3-1 A/dm² | Exceeding burns edges on first loads |
| Rotation | 6-12 r/min | Heavy parts low speed; light parts higher |
| First-load check | 5 min after ramp start | Catches coverage problems before full cycle |
A scale on every drum
Scenario. Loads were judged by eye; first loads burned and last loads under-plated.
Action. Weigh-every-load discipline with a per-drum loading chart.
Result. Edge burns on first loads disappeared within the first week.
Frequently Asked Questions
Is a full drum more output?
No. Above 45% volume parts stop tumbling and coverage fails. 35-45% is the working band.
Why did edges burn on the first load?
Cold-start current without a ramp. Start at 55% of target for three minutes, then ramp.
How often should I weigh loads?
Every load. Volume estimation fails silently and consistently.
Implementation Roadmap
| Step | Frequency |
|---|---|
| Loading chart posted per drum | Day 1 |
| Load weighing discipline check | Every shift |
| OEE baseline measured | Week 2-4 |
What Would You Like to Solve?
If you would like this checklist or template adapted to your own line and part mix, contact QLQ we supply the full equipment and chemistry package along with the working documents that make it run.
